Product Description

Downdraft Grinding Table

Suitable for grinding, polishing and other working conditions of metal and non-metal workpieces.



Performance Description

1- Integral structure, beautiful appearance, small floor area, easy to move and fix with Fuma wheel installed at the bottom.

2- Three sides surrounding design, effectively preventing the spread of dust.

3- Multi-stage high efficiency filtration, up to emission standard.

4- Drawer dust box, convenient and quick to pour dust.

5- Dustproof 5-hole socket, convenient to connect with electric tools.

6- Removable modular work surface



Standard Configuration

1- Aluminium alloy flame arrestor

2- Primary filter

3- HEPA filter

4- Dustproof 5-hole socket

5- 12L dust drawer

6- 5m power cord



Optional Components

1- Non-slip soft pad

2- IO Port (remote control)

3- Stainless steel custom machine structure

4- Working surface can be designed as round hole, square hole, long hole.

5- Working surface can be stainless steel, brass, nylon, polyurethane.



Technical Parameters

	MLWF100D	MLWF150D	MLWF200D
Motor Power	1.1KW	1.5KW	1.1KW*2
Working Voltage	220V 50Hz	380V/50Hz	380V/50Hz
Air Volume	1500m^3/h	2500m^3/h	3000m^3/h
Filtering Accuracy	0.3um	0.3um	0.3um
Filter Material	Aluminium alloy flame arrestor, Primary filter, HEPA filter
Cleaning Mode	Manual	Manual	Manual
Noise Level	75±3dBA	75±3dBA	75±3dBA
Dimension	1000*600*1000mm	1500*800*1000mm	2000*800*1000mm
Weight	105kg	150kg	260kg

Payment Terms︰ T/T

Product Image
