Manual Welding Fume Extractor Movable Welding Dust Smoke Purifier

  • Manual Welding Fume Extractor Movable Welding Dust Smoke Purifier
  • Manual Welding Fume Extractor Movable Welding Dust Smoke Purifier
  • Manual Welding Fume Extractor Movable Welding Dust Smoke Purifier
  • Manual Welding Fume Extractor Movable Welding Dust Smoke Purifier
  • Manual Welding Fume Extractor Movable Welding Dust Smoke Purifier
Model No.︰MLWF290
Brand Name︰Moland
Country of Origin︰China
Unit Price︰US $ 1692 / pc
Minimum Order︰1 pc
Share on:

 Total 20 Related Items
Prev1415161718Next

Product Description

Suitable for welding fume, cutting fume dust, laser welding cutting fume, plasma cutting fume, polishing dust, drilling dust, mixing and cutting materials to produce fume dust.


Performance Description
1- Integral structure, with universal wheel at the bottom, flexible movement and fixing.
2- Power supply condition monitoring: alarm for broken phase overvoltage and undervoltage to prevent motor and electrical components from damage.
3- Pneumatic condition monitoring: alarm of low pressure of gas source to prevent incomplete ash cleaning, differential gauge to visually show the use status of fillter element, automatic pulse back blowing of high pressure difference.
4- Opereating temperature monitoring: alarm system temperature is too high, preventing fire.


Standard Configuration
1- Filteration efficiency (>99.9%) of main filter core (covered polyester fiber)
2- Fault phase protection, overload protection, air pressure monitoring and temperature monitoring devices
3- PLC Pulse Controller
4- Differential pressure gauge
5- 20L dust drawer
6- 10m power cord
7- Universal flexible arm (dia.160*3000)
8- Spark trap (large particle dust pre-filter)

Spare Parts
1- IO port (remote control)
2- Explosion proof configuration

Recommended Working Condition
1- Welding robot
2- Special machine for Ring and Straight Welding

Payment Terms︰T/T
Product Image
